Description

PVC Bag Filter Housing

In modern industrial operations, maintaining the purity and quality of fluids is essential. One of the most efficient and cost-effective methods to achieve this is by using a PROFILTER PVC Bag Filter Housing.

PT PROFILTER INDONESIA adalah importir distributor agen dan supplier Housing Filter terlengkap menyediakan berbagai kebutuhan spare part water treatment untuk keperluan industri dengan kualitas dan harga terbaik.

Overview PVC Bag Filter Housing

A PVC Housing Filter Bag is a liquid filtration unit made from Polyvinyl Chloride (PVC) that holds a filter bag inside a pressure-resistant container. It is designed to remove particles and impurities from fluids efficiently in light to medium-duty applications.

Unlike stainless steel housings, PVC filter housings offer a lightweight, chemical-resistant, and budget-friendly solution. They are ideal for processes that don’t require high temperature or high-pressure resistance.

Key Benefits of PVC Housing Filter Bags

• Affordable Solution
  • PVC housing is a low-cost alternative to metal housings, without compromising basic filtration performance.
• Lightweight and Easy to Install
  • The lightweight design makes it simple to install and move for temporary or mobile applications.
• Chemical Resistance
  • PVC is suitable for filtering non-corrosive fluids and a range of mild chemicals.
• Low Maintenance
  • Easy access for bag replacement and cleaning with minimal downtime.

Technical Specifications

• Material: Polyvinyl Chloride (PVC)
  • Bolt & Nut – SUS 316
  • Sealing Silicone  O-ring
• Filter Capacity: 1 to 3 filter bags (customizable)
• Connection Types: 2″ Threaded or flanged
• Closure
  • PFI PBU – Union
  • PFI PBB – Bolt and Nut
• Bag Sizes Supported: Size #1, #2, or customized
• Pressure Rating: Up to 3 bar
  • PFI PBU – Max. 60 psi, continuous 45 psi
  • PFI PBB – Max.100 psi, continuous 75 psi
• Temperature Limit: Up to 45–50°C
• Optional Add-ons: Pressure gauge, air vent, drain valve

PFI Industrial Grade Liquid Filter Bag Cartridge Housing & Vessels
Strain or filter away contaminants with these industrial Single Bag Filter Vessels. When unfiltered liquid enters the housing, solids are contained inside the basket for easy removal. Choose from maximum working pressures of 100, 150, or 300 PSI with a -300°F maximum working temperature. These liquid Cartridge filter bag housing and vessels are made of aluminum, carbon steel, polypropylene (PP), stainless steel 304, or stainless steel 316L.

Applications

• Pre-filtration for reverse osmosis systems
• Pre-filtration for ion exchange and UV units
• Commercial buildings
• Food service
• Car washes
• Agriculture
• Hospitals
• Bottled water
• Process water
• Seawater filtration

Why Choose Our PVC Housing Filter Bags?

• Trusted Quality – Manufactured under strict quality standards
• Complete Stock Available – Ready-to-ship in various models and sizes
• Free Technical Support – Get expert advice on filtration system selection
• Customizable Options – Designed to match your industrial process perfectly

Conclusion

If you’re seeking a cost-effective, low-maintenance, and lightweight filtration system, our PVC Housing Filter Bag is a smart choice. It’s perfect for a wide range of industrial uses where metal housings may be excessive or unnecessary.
